Light output

6500 Center lumen
6000 ANSI Lumen

Resolution

1400 x 1050 (native)

Brightness uniformity

> 90% for the total screen

Contrast ratio

1600:1 (full field)

Display

3 Chip DLP SXGA+ (resolution of 1400 x 1050 pixels (aspect ratio 4:3)).

Convergence

Max allowed convergence drift is 0.5 pixel.
This is checked on vertical and horizontal midlines only.
Corners are not applicable for convergence error.
This is measure with TLD 1.2 lens on axis.

Features

• AutoImage
• Advanced picture-in-picture
• Seamless switching with effects
• Standard light shutter
• Advanced digital zoom
• Rigging point
• Carrying handle
• Frame
• P7 color processing

Picture-in-picture

Up to 4 sources simultaneously (2 data, 1 video and 1 SDI)

Inputs

Fixed inputs

• 1x Configurable 5-Wire (BNC)
• 1x Composite Video (BNC)
• 1x S-Video (4-pin mini-DIN)
• 1x analogue RGB (D15 connector)
• 1x SDI/HDSDI (+ loop through)
• 1x DVI (Digital Visual Interface)

Outputs

HDSDI/ SDI loop out

Communication

• 1x RS-232C IN (D-9 connector)
• 1x RS-232C OUT (D-9 connector)
• 1x RS-232C IN (XLR connector)
• mini-jack for wired remote control

Compatibility

• All current video sources (PAL, SECAM, NTSC) in Composite, S-VHS, Component or RGB formats
• All currently proposed HDTV, extended and improved television standards (1080i, 720p)
• All computer graphics formats from VGA, SVGA, XGA, SXGA,full HD to UXGA
• Most Macintosh computers
• Electronic workstations with a resolution up to 1600 x 1200 pixels at 75 Hz
• Most computer sources with a pixel clock up to 200 MHz
• DVI sources up to SXGA+

Input source compatibility

1600 x 1200 (max. input)

Screen size

From 1-7m / 3-23ft.recomended

Scan Frequencies

Pixel clock >162Mhz (UXGA 60hz)

Network connection

Optional (10 base-T)

Ambient temperature

Max 40°C (104°F)

Lamp

2 x 250 W mercury

Lamp warranty: 1000 hrs

Lenses

Lens Shift

Vertical: -10% to +110%
Horizontal: -50% to +50%
(small differences occur per lens type)

Lens encoders

On zoom and focus (with TLD lenses)

ScenergiX

Standard horizontal and vertical electronic edge blending

Sealed DLP™ core

Standard

Dust filters

Metal filters

Noise Level

42 dB(A) (at 40°C)

Mains Voltage

92-240 V / 50 - 60 Hz

Power consumption

700 W

Power Dissipation

Max 2217 BTU/h

AC power

90V - 255V
(50 Hz - 60Hz)

Weight

Projector: 25 kg (56 lbs)
Frame: 5 kg (11 lbs)

Dimensions

W x L x H
705 x 707,8 x 316,5 mm
(27.8 x 27.9 x 12.5 inch)

Shipping Dimensions

Width: 56 cm
Height: 100 cm
Depth: 100 cm
Floor Space: 1 m²
Volume: 0,56 m³
Gross Weight: 65 kg

Safety Regulations

Compliant with UL1950 and EN60950

Electromagnetic Interference

Complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A

Order Information

Projector body (without lens): R9010270
Spare dual lamp: R9852940
